Waveshare Industrial USB to RS485 Bidirectional Converter
Waveshare Industrial USB to RS485 Bidirectional Converter The Waveshare Industrial USB to RS485 Bidirectional Converter is a robust and reliable communication interface designed for industrial applications. Featuring the original CH343G USB bus adapter chip and high-performance SP485EEN transceivers, this converter ensures stable, high-speed communication with excellent compatibility. It converts USB signals into balanced differential RS485 signals, offering transmission speeds from 300bps up to 3Mbps and a communication range of up to 1.2km for RS485 and 5 meters for USB. Built-in protection circuits, including lightning-proof tube, resettable fuse, ESD, and TVS protection, enhance durability and safeguard against harsh electrical environments. Supporting automatic baud rate recognition up to 115200bps, the converter allows easy integration of traditional serial devices or microcontrollers into modern USB interfaces, making it an ideal solution for industrial automation, monitoring systems, and other serial communication projects. Features: Supports bidirectional USB-to-RS485 conversion Fast connectivity, stability and reliability, improved compatibility Onboard TVS (Transient Voltage Suppressor) effectively suppress surge voltage and transient spike voltage in the circuit, lightning proof, and anti-electrostatic. Onboard resettable fuse and protection diodes assure current/voltage steady outputs, provide over-current/over-voltage protection, and improve shock resistance. 3 LEDs to show the power and transceiver status.
- Industrial-grade USB to RS485 bidirectional converter
- Onboard original CH343G chip for USB to serial conversion
- Integrated SP485EEN transceiver for improved stability and compatibility
- Supports 300bps to 3Mbps transmission speed
- RS485 range: up to 1.2km; USB cable range: up to 5 meters
- Built-in lightning-proof tube, resettable fuse, ESD, and TVS protection
- Auto baud rate detection (up to 115200bps)
- Ideal for upgrading serial devices or MCUs to USB communication
- Model Type Converter
- Operating Voltage 5V
- Host Port USB
- Device Port RS485
- Baud Rate 300bps ~ 3Mbps
- Connector Type USB-A
- Transmission Distance Up to 5 meters (USB), up to 1.2km (RS485)
- Protection Features 200mA self-recovery fuse, ESD protection, TVS diode, lightning-proof tube
- Operating Humidity 5%RH ~ 95%RH
- Transmission Mode Point-to-multipoint (up to 32 nodes; use repeaters for 16+ nodes)
- Status Indicators TXD: Red LED (USB data transmission)RXD: Red LED (RS485 data reception)
