LJ12A3-4-Z/BX NPN 24V Approach Sensor Inductive Proximity Switch This Tube Type Inductive Proximity Sensor Detection Switch NPN DC5-36V 4mm Normally Open switch LJ12A3-4-Z/BX is a component widely used in the automatic control industry for detecting, controlling, and non-contact switching. When the proximity switch is close to some target object, it will send out a control signal. When the metal approaches the near-proximity switch sensing area, an Edy Current is induced in the metal. Which in turn disturbs the magnetic field produced by the Inductive Proximity Sensor. This change is sensed by the sensor. These inductive proximity switches can be non-contact, no pressure, no spark, quickly issued the electrical command. Accurately reflect the position and stroke movement mechanism. Positioning accuracy, operating frequency, service life. Easy to install and suitable for harsh environments. This 4mm proximity sensor can detect a variety of metals, miniature size, long life, low price, shielded type installation, anti-interference ability, 1mm detection distance, used for precise positioning of molds, precision machine tools, and robots. check out : Tube Type Inductive Proximity Sensor Detection Switch NPN DC5-36V 4mm Normally Open switch LJ12A3-4-Z/BX Applications: It is a component widely used in automatic control industry for detecting, controlling, and noncontact switching. It's widely used in machiness, paper making, light industry for limiting station, orientation taking counts, speeding trials, etc. Also, read our blog Types of Proximity Sensor detailing 5 types of proximity sensors and their working principles.

LJ12A3-4-Z/BY PNP DC 6-36V 4mm Tube Type Inductive Proximity Sensor Switch The LJ12A3-4-Z/BY inductive proximity sensor is a reliable and compact component designed for precise non-contact detection of metallic objects. Operating on a DC 6-36V PNP configuration, this 4mm tube-type sensor provides accurate positioning and fast response, making it ideal for industrial automation applications. When a metal object enters the sensing area, the inductive proximity sensor generates an Eddy Current that alters its magnetic field, allowing it to issue a quick electrical command without physical contact. With features such as long service life, excellent anti-interference capability, and easy installation, the LJ12A3-4-Z/BY is well-suited for use in molds, precision machine tools, robotics, and other demanding environments where reliability and durability are crucial. Features: A red LED indicates the proximity sensor's status. High repeatable positioning precision. High switching frequency. Wide voltage range. The whole length of the cylinder is 62mm. Thread length: 40mm. Outer (thread) diameter: M12. Antivibration, dust, water, and oil protection Reverse power protection, short circuit protection, and direct connection with PLC. Can replace tiny and limit switches.

LJ18A3-8-Z-BX 8mm Inductive Proximity Sensor The LJ18A3-8-Z/BX proximity sensor will detect large metal fields at an 8mm distance with great precision. This allows you to accurately measure the distance to an (aluminum) heated bed for example. If you are using a glass plate as your print surface, you can use aluminum foil right below the glass, which will also be detected by the sensor (mirrors however are not detected). The sensor is equipped with a small red detection LED, indicating a nearby object. The sensor has M18 threading and includes a nut for easy mounting to your 3D printer or CNC machine. The LJ18A3 is a PNP Normally Open (NO) type of proximity sensor. This means that the signal lead will output a positive voltage (same as the input voltage) when a metal mass is detected. When nothing is detected, the signal is equal to ground. Most modern 3D printer firmware has some sort of auto bed leveling procedure available, but you will need to enable it. You can use this sensor as the z_min_endstop for example, replacing your current end stop. Most firmware will also use the min end stop as a probe, but some allow a separate probe to be defined. This sensor operates at 5-36V, so as the signal voltage is the same as the input voltage, also the signal will be 5-36V. You will need to down-convert the voltage to an acceptable level for your electronics. Please see the linked schematic on how to connect this sensor to the end stop pins of your electronics board. Check out the best selection of Proximity Sensors . Read our blog Proximity Sensor Types where we explained what is a proximity sensor, different types of Proximity Sensors and their working principle. Wiring: Wire - red or brown - supply voltage - V 5 Wire - green or blue - ground - GND Wire - yellow or black - digital output - OUT there is no object - high status the object detection - low status Application: Mine metallurgy. Plastics, textile, and Chemical Industry. Light industry, tobacco, electric power, railway, and war industry. Read our blog about how does a proximity sensor work where we discuss what proximity sensors are, the features of proximity sensors, how does proximity sensor work, and the different types of proximity sensors. Also check out the blog Interfacing Proximity Sensors with Arduino, where you can get the proximity sensor code .

.

LM 741 Op-Amp IC The LM741 Op-Amp integrated circuit is a general-purpose operational amplifier that outperforms industry standards such as the LM709. In most applications, they are direct, Exceeded plug-in replacements for the 709C, LM201, MC1439, and 748. Many features of the amplifiers make their application nearly foolproof: overload protection on the input and output, no latch-up when the common mode range is exceeded, and freedom from oscillations. The LM741C is identical to the LM741 and LM741A except that its performance is guaranteed over a temperature range of 0°C to +70°C rather than 55°C to +125°C. The LM741 is a general-purpose operational amplifier IC that has been widely used in electronic circuits for over four decades. It is known for its simplicity, reliability, and versatility, and it can be used in a variety of analog applications. Pinout: Pinout of LM741 Op-Amp IC Applications: Amplifiers. Voltage follower circuits. Clipping Amplifier Circuit. Summing amplifier or adder circuit. General feedback applications.

LM10UU 10mm Linear Motion Bearing for 3D Printer LM10UU 10mm Linear Motion Bearings are perfect for linear motion on your 3D Printer, CNC, or other applications. It provides a precise, safe, and reliable linear motion system. This is Linear Motion Bearing closed type ball bushing that has a 10mm bore and 19mm outer diameter and is suitable for use in a mounted slide unit to carry components. These Bearings have various standardized parts which are interchangeable, so you need not worry about the replacement of any worn parts. LM 10 UU Linear Motion Bearing is High Precision and Rigidity linear motion bearings are produced from a solid steel outer cylinder. Also, the linear motion bearing incorporates an industrial-strength resin retainer. LM10UU Linear Motion Bearing is Ease of Assembly The standard type of linear motion bearing can be loaded from any direction. This Linear Motion Bearing is a linear motion bearing that consists of an outer cylinder, ball retainer, balls, and two end rings. The ball retainer which holds the balls in the recirculating trucks is stored inside the outer cylinder by end rings. Those parts are assembled to optimize their required functions. Applications: 3D Printer CNC Machines DIY Mechanical Projects Industrial Equipments

LM1117 IC Transistor - 3.3V Voltage Regulator The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current. The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 to 13.8 V with only two external resistors. LM1117 offers current limiting and thermal shutdown. Its circuit includes a Zener trimmed bandgap reference to assure output voltage accuracy to within ±1%.

LM12UU 12mm Linear Motion Bearing for 3D Printer LM12UU 12mm Linear Motion Bearings are perfect for linear motion on your 3D Printer, CNC, or other applications. It provides a precise, safe, and reliable linear motion system. This is Linear Motion Bearing closed type ball bushing that has a 12mm bore and 21mm outer diameter and is suitable for use in a mounted slide unit to carry components. These Bearings have various standardized parts which are interchangeable, so you need no worry about the replacement of any worn parts. LM12UU Linear Motion Bearing is High Precision and Rigidity linear motion bearings are produced from a solid steel outer cylinder. Also, the linear motion bearing incorporates an industrial strength resin retainer. LM 12 UU Linear Motion Bearing is Ease of Assembly The standard type of linear motion bearing can be loaded from any direction. This Linear Motion Bearing is a linear motion bearing that consists of an outer cylinder, ball retainer, balls, and two end rings. The ball retainer which holds the balls in the recirculating trucks is stored inside the outer cylinder by end rings. Those parts are assembled to optimize their required functions. Applications: 3D Printer CNC Machines DIY Mechanical Projects Industrial Equipments Also check the LM13UU 13mm Linear Motion Bearing for 3D Printer available on Iotcart. The bearing is designed for precise, safe, and reliable linear motion in various applications such as 3D printers, DIY projects, and robotics prototyping.

LM13UU 13mm Linear Motion Bearing for 3D Printer LM13UU 13mm Linear Motion Bearings are perfect for linear motion on your 3D Printer, CNC, or other applications. It provides a precise, safe, and reliable linear motion system. This is Linear Motion Bearing closed type ball bushing that has a 13mm bore and 23mm outer diameter and is suitable for use in a mounted slide unit to carry components. These Bearings have various standardized parts which are interchangeable, so you need no worry about the replacement of any worn parts. LM 13 UU Linear Motion Bearing is High Precision and Rigidity linear motion bearings are produced from a solid steel outer cylinder. Also, the linear motion bearing incorporates an industrial strength resin retainer. LM 13 UU Linear Motion Bearing is Ease of Assembly The standard type of linear motion bearing can be loaded from any direction. This Linear Motion Bearing is a linear motion bearing that consists of an outer cylinder, ball retainer, balls, and two end rings. The ball retainer which holds the balls in the recirculating trucks is stored inside the outer cylinder by end rings. Those parts are assembled to optimize their required functions. Applications: 3D Printer CNC Machines DIY Mechanical Projects Industrial Equipments

LM2577 DC-DC Step-up Power Converter Module The LM2577 is a DC to DC step-up switching regulator that can provide an adjustable output ranging from +1.25 to 30vdc with a maximum current of 3A. While it is primarily designed to step up +5 to 10vdc to +12vdc at less than 1A, the maximum step-up voltage and current available depend on the input voltage. For instance, with an input voltage of +5vdc, you can expect to get 12vdc output at less than 1A. This device is well-suited for battery-operated projects that require a regulated power supply, as it boasts a low output ripple thanks to its additional filtering capabilities. It is an adjustable power supply step-up module with a maximum input current of 3A and an impressive conversion efficiency of up to 92%, making it an excellent choice for DIY mobile power or boost charger projects. Features: Wide Input voltage: 3.5V-35V Output Voltage: 4-35V (Adjustable) Output current: rated current 3A MAX ( Heat-sink Needed) Conversion efficiency: Up to 92% (output voltage higher, the higher the efficiency) Switching Frequency: 50KHz Rectifier: Non-Synchronous Rectification Short circuit protection: current limiting, since the recovery High-quality PCB FR4 Grade with FPT Certified check out : PCF8591 ADC-DAC Converter Module
