74HC165 - 8-Bit Parallel In/Serial Out Shift Register IC The 74HC Series 74HC165 high-speed PARALLEL-IN/SERIAL-OUT SHIFT REGISTER utilizes advanced silicon-gate CMOS technology. It has the low power consumption and high noise immunity of standard CMOS integrated circuits, along with the ability to drive 10 LS-TTL loads. This 8-bit serial shift register shifts data from QA to QH when clocked. Parallel inputs to each stage are enabled by a low level at the SHIFT/LOAD input. Also included is a gated CLOCK input and a complementary output from the eighth bit. Clocking is accomplished through a 2-input NOR gate permitting one input to be used as a CLOCK INHIBIT function. Holding either of the CLOCK inputs high inhibits clocking, and holding either CLOCK input low with the SHIFT/LOAD input high enables the other CLOCK input. Data transfer occurs on the positive-going edge of the clock. Parallel loading is inhibited as long as the SHIFT/LOAD input is HIGH. When taken LOW, data at the parallel inputs are loaded directly into the register independent of the state of the clock. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and the ground. check out : 4-bit Parallel-Access Shift Register IC - 74HC95 Pinout: Pinout Of 74HC165

74HC20 - Dual 4-input NAND Gate IC The 74HC Series 74HC20 is a 14-Pin Quad 4-Input NAND Gate IC. This device contains four independent gates each of which performs the logic NAND function. NAND gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. All gates have buffered outputs. All devices have high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground. check out : Triple 3-Input NAND Gate IC - 74HC10 Pinout: Pinout Of 74HC20 IC

Product Information Logic Case Style: DIP Logic Type: Decoder / Demultiplexer MSL: - No. of Outputs: 8 No. of Pins: 16 Operating Temperature Max: 125 °C Operating Temperature Min: -40 °C Packaging: Each SVHC: No SVHC (17-Dec-2014) Supply Voltage Max: 6 V Supply Voltage Min: 2 V

74HC32 - Quad 2-Input OR Gate IC The 74HC Series's 74HC32 IC is a 14 Pin Quad 2-Input OR Gate IC. The 74HC32 provides four independent 2-input OR gates with standard push-pull outputs. The device is designed for operation with a power supply range of 2.0V to 6.0V.  Inputs include clamp diodes. This enables the use of current-limiting resistors to interface inputs to voltages in excess of VCC. Pinout: Pinout of 74HC32 IC Input Pins 1, 2, 4, 5, 9, 10, 12, 13 Inverting Output Pins 3, 6, 8, 11 Power Supply ( VCC) 14 Ground (GND) 7 Application: Toys Musical Instruments Medical Healthcare and Fitness Grid Infrastructure Electronic Point of Sale Test and Measurement Factory Automation and Control Building Automation

74HC74 - Dual D-type Positive Edge-triggered Flip-Flops IC The 74HC Series 74HC74 device contains two independent positive-edge-triggered D flip-flops with complementary outputs. The information on the D input is accepted by the flip-flops on the positive-going edge of the clock pulse. The triggering occurs at a voltage level and is not directly related to the transition time of the rising edge of the clock. The data on the D input may be changed while the clock is LOW or HIGH without affecting the outputs as long as the data setup and hold times are not violated. A low logic level on the preset or clear inputs will set or reset the outputs regardless of the logic levels of the other inputs. Pinout: Pinout Of 74HC74 IC Input (1D, 2D) 2, 12 Inverting Output  (1Q', 2Q') 6, 8 Non-Inverting (1Q, 2Q) 5, 9 Clock (1CLK, 2CLK) 3, 11 Enable Pin (ENP, ENT) 4, 10 RESET (R') 1,13 Power Supply ( VCC) 14 Ground ( GND ) 7 Application: Ultrasound System Fans Lab Instrumentation Vacuum Cleaners Video Communications System IP Phone: Wired

74HC76 - Dual JK Flip-Flop with Set and Clear IC The 74HC Series 74HC76 offers individual J, K, Clock Pulse, Direct Set, and Direct Clear inputs. These dual flip-flops are designed so that when the clock goes HIGH, the inputs are enabled and data will be accepted. The Logic Level of the J and K inputs will perform according to the Truth Table as long as minimum set-up times are observed. Input data is transferred to the outputs on the HIGH-to-LOW clock transitions. Pinout: PIN No SYMBOL NAME AND FUNCTION 1, 6 1CK, 2CK Clock Input(HIGH to LOW edge triggered) 2, 7 1PR, 2PR Set Inputs (Active LOW) 3, 8 1CLR, 2CLR Asynchronous Reset Inputs (Active LOW) 4, 9 1J, 2J Data Inputs: Flip-Flop 1 and 2 10, 14 1Q,2Q Complement Flip-Flop Outputs 11, 15 1Q,2Q True Flip-Flop Outputs 16, 12 1K,2K Data Inputs: Flip-Flop 1 and 2 13 GND Ground (OV) 5 Vcc Positive Supply Voltage

74HC86 - Quad 2-Input EXOR Gate IC The 74HC Series 74HC86 is Quad 2-Input EXOR Gate 14 Pin IC. It is an advanced high-speed CMOS 2?input Exclusive?OR gate fabricated with silicon gate CMOS technology. It achieves high speed operation similar to equivalent Bipolar Schottky TTL while maintaining CMOS low power dissipation. The internal circuit is composed of three stages, including a buffer output which provides high noise immunity and stable output. Inputs tolerate voltages up to 7V, allowing the interface of 5V systems to 3V systems. Used for Building Arithmetic Logic Circuits, Computational Logic Comparators, and Error Detection Circuits and True/Complement Elements. Pinout: Pinout Of 74HC86 IC Input Pin 1, 2, 4, 5, 9, 10, 12, 13 Output Pin 3, 6, 8,11 Power Supply (VCC) 14 Ground (GND) 7

'--

74LS109 Dual J-K Positive Edge-Triggered Flip-Flop IC The 74LS109 Dual J-K Positive Edge-Triggered Flip-Flop IC, also referred to as the 74109 IC, features two independent flip-flops designed for positive-edge clock triggering. Each flip-flop includes asynchronous preset and clear inputs that can override all other signals, ensuring reliable reset or set operations. This JK flip-flop IC allows flexibility in design—it can function as a toggle flip-flop by grounding the K input and tying J high, or as a D-type flip-flop by connecting both J and K inputs. The 74109 IC is ideal for timing, data storage, and sequential logic applications, supporting a temperature range of 0°C to 70°C. With a variety of packaging options, including plastic and ceramic DIPs, this IC is a trusted choice for TTL-based digital systems. Features: Dual J-K positive-edge-triggered flip-flops Asynchronous preset and clear inputs Edge-triggered clock input for precise timing Operates as JK or D-type flip-flop TTL compatible logic levels Low power consumption Noise-immune circuitry

'--
