Seeed Studio XIAO RP2350 Development Board Support Micropython / C, C++

Official Arduino UNO Q SBC 4GB ABX00173 The Arduino UNO Q SBC 4GB ABX00173 is a powerful and humanized dual-brain development platform designed to seamlessly bridge high-performance computing with real-time control. Featuring a Linux® Debian-capable Qualcomm® Dragonwing™ QRB2210 microprocessor alongside a real-time STM32U585 microcontroller (MCU), this 4GB variant delivers enhanced memory capacity for demanding AI-driven applications. Whether you're building systems for object recognition, voice commands, motion detection, or other intelligent edge applications, the Arduino UNO Q 4GB provides the perfect balance between a full-fledged single-board computer and precise microcontroller control. It’s not just Arduino—it’s a complete innovation platform ready to power your next advanced project. This edition of Arduino UNO Q has 4 GB of RAM and 32 GB of eMMC, making it the best choice if: You plan to use UNO Q in single-board computer (SBC) mode. Your application requires numerous high-level processes to execute at the same time. You intend to use larger, more complex AI or machine learning models (such as high-resolution computer vision or advanced audio processing). You'll need enough of built-in storage for logs and data, as well as a strong development environment. The Arduino UNO Q is the ideal tool for prototyping your next robotics or IoT project because: All-in-One Toolbox: The Arduino UNO Q is a versatile tool that combines the Dragonwing™ QRB2210 microprocessor (MPU) with a real-time STM32U585 microcontroller (MCU), making it ideal for any project. AI in a blink: Discover AI-powered vision and sound solutions that respond to their surroundings. Millions of Arduino users have created libraries, sketches, and projects for the UNO ecosystem. Compatible with the Arduino UNO ecosystem: UNO Q is compatible with a wide range of Arduino hardware, including old UNO shields and new carriers, as well as Modulino® nodes and third-party modules via the Qwiic connector. Streamlined software experience: In addition to the Arduino IDE and Arduino Cloud, you can get started with a plethora of pre-built examples and AI models available through Arduino App Lab. Seamless, unified development: create classic Arduino Sketches, code in Python® using the pre-installed Linux® Debian OS, or combine the two from a single interface - easy with Arduino App Lab. What is the Arduino App Lab? Unified Developer Experience App Lab is a brand-new comprehensive development environment that unifies the journey from Linux® to real-time OS. Preloaded on the UNO Q, App Lab combines Arduino Sketches, Python® scripts, and containerized AI models to create fully integrated applications that can be administered from a single interface. Ready-to-use Apps and Bricks Get started quickly with Arduino Apps, self-contained examples that include everything you need. Add plug-and-play capabilities to your projects using pre-built Bricks to help you push your ideas even further. Pre-loaded AI models With pre-loaded AI models in Arduino App Lab, you can use real-world data for a variety of tasks, including object/human detection, anomaly detection, image categorization, sound recognition, and keyword spotting. Find out more in the official documentation . Features: Microprocessor: Qualcomm® Dragonwing™ QRB2210 Microcontroller: Real-time, low-power STM32U585 MCU RAM: 4 GB LPDDR4 Storage: 32 GB eMMC built-in (no SD card required) Connectivity: Dual-band Wi-Fi® 5 (2.4/5 GHz), Bluetooth® 5.1 High-speed headers: Power advanced peripherals – vision, audio, display Classic UNO headers: Mount shields to add capabilities LED matrix: 8 x 13 LED matrix for visual creation and feedback USB-C connector: Power delivery, video output, or connect keyboard, mouse, USB microphones or USB cameras via dongle Qwiic connector: Expand easily with Modulino® nodes – no soldering required

7Semi Compact FT232 USB-C UART (TTL) Communication Module The 7Semi Compact FT232 USB-C UART (TTL) Communication Module is a reliable and easy-to-use USB UART Module designed for stable USB-to-TTL serial communication. Powered by the FT232RNL chip, it ensures accurate data transfer between USB ports and microcontrollers, development boards, or embedded systems. With support for both 5V and 3.3V logic levels, this USB UART Module adapts easily to different hardware requirements. Its USB Type-C interface enhances durability and connectivity, while the onboard TX and RX LEDs provide clear visual feedback during data transmission, making it ideal for debugging, programming, and serial communication applications. Features: Time-saving: With quick setup and straightforward use, you can focus on your job rather than connectivity issues. Wide Application: It is compatible with a wide range of TTL devices, making it suitable for a variety of projects. Project tracking allows you to easily monitor data flow and ensure that everything goes properly. Adaptable: The flexible power and logic levels accommodate a wide range of development situations. FT232 devices provide two driver options: VCP (Virtual COM Port): Ideal for simple projects in which you want your device to behave like a conventional serial device. D2XX: Provides greater control and flexibility, but requires programming using API functions. Select this if you require advanced functionality.

Cytron PS2 Shield for Arduino The Cytron PS2 Shield is a compact and reliable PS2 controller interface designed for Arduino boards, making remote control projects smoother and far more intuitive. Whether you're working with an Arduino Uno, Mega, Leonardo, or other compatible boards, this shield lets you easily integrate a wired or wireless PS2 controller into your robotics, DIY RC projects, or gaming-inspired builds. With simple UART communication and a plug-and-play connector, reading joystick inputs and button states becomes effortless, even for beginners. Built with developers and hobbyists in mind, the Cytron PS2 Shield provides flexible UART selection options, stackable headers for adding more shields, and support for vibration motors on PS2 controllers. Because it draws power directly from the Arduino board, setup stays clutter-free. This PS2 Shield is perfect for anyone looking to add remote control, robotics maneuvering, or wireless navigation to their Arduino-based projects using a familiar PS2 controller format. Features: Provides an easy and reliable interface for connecting wired or wireless PS2 controllers to Arduino boards. Supports multiple Arduino models including UNO, Mega, Leonardo, and other pin-compatible variants. Simple UART-based communication allows effortless reading of joystick and button states. Integrated support for controlling the PS2 controller’s vibration motor for enhanced feedback. Stackable headers enable additional shields to be mounted above the PS2 Shield without conflict. Jumper-based selection for baud rates (9600, 57600, 115200) and configurable UART TX/RX pins. Fully powered from the Arduino main board with low current consumption. Includes status LED and reset control via Arduino A1 pin for convenient operation.

Cytron CM4 Maker Board for Raspberry Pi The Cytron CM4 Maker Board is a powerful and reliable development board built around the Raspberry Pi Compute Module 4 (CM4), designed specifically for Pro Makers, hardware hobbyists, educators, and embedded developers. With its wide input voltage range, convenient power button, and multiple boot options - including microSD, NVMe SSD, and CM4 eMMC, this Cytron board gives makers complete flexibility in how they build, experiment, and deploy their Raspberry Pi projects. It also retains essential interfaces like Gigabit Ethernet, USB 2.0 ports, HDMI, CSI, and DSI, ensuring compatibility with Raspberry Pi HATs and common accessories. Cytron enhances the standard CM4 experience by adding practical maker-friendly features such as on-board RTC (PCF85063A), Grove ports, Maker Port, 10 GPIO status LEDs, a piezo buzzer with mute switch, and dedicated push buttons. Whether you are creating IoT prototypes, robotics systems, dashboards, or long-running automation projects, the Cytron CM4 Maker Board offers stability, bigger storage options, real-time clock capability, and the expandability required for advanced Raspberry Pi development. Features: The Cytron CM4 Maker Board supports a wide input voltage range through a 7–18V DC jack or 5V USB-C, making it adaptable for various maker setups. Cytron includes a convenient hardware power button, allowing safe shutdown and easy startup without needing terminal commands. The board supports multiple boot sources, including microSD, NVMe SSD (2230/2242), and onboard eMMC on CM4 for faster and more reliable storage. Includes all essential Raspberry Pi features like Gigabit Ethernet, 4× USB 2.0 ports, HDMI, CSI camera port, DSI display port, and 3.5mm audio out. Equipped with PCF85063A RTC, enabling real-time clock functionality even without an internet connection. Cytron adds maker-focused extras such as Grove ports, Maker Port, 10 GPIO LEDs, piezo buzzer, and push buttons for quick prototyping. Pinout Diagram:

Cytron SHIELD-3AMOTOR 1.2A Dual Channel 7V–30V DC Motor Driver Shield for Arduino The Cytron SHIELD-3AMOTOR is a high-performance, dual-channel DC motor driver shield designed for Arduino users who need reliable and efficient motor control. Supporting motor voltages from 7V to 30V and delivering up to 3A peak and 1.2A continuous current per channel, this shield is ideal for robotics, automation, DIY RC vehicles, and mechatronics projects. Its compatibility with Arduino UNO, Mega, Leonardo, Zero, 101, and other popular boards makes it a plug-and-play solution for both beginners and advanced makers searching for powerful motor-driving capabilities. Built using the DRV8871 motor driver IC, the Cytron SHIELD-3AMOTOR supports both Signed Magnitude and Locked Anti-Phase control modes via an easy DIP switch selector. Additional features such as current limit protection, stackable headers, quick-test pushbuttons, and direct connectors for the LSS05 auto-calibrating line sensor make this shield perfect for building reliable robot platforms, line-followers, and dual-motor systems. With strong motor handling and seamless Arduino integration, this Cytron shield makes high-current motor control simple, safe, and efficient. Features: Dual-channel brushed DC motor driver shield designed for full Arduino compatibility. Supports 7V–30V motor voltage, suitable for a wide range of DC motors. Handles 3A peak and 1.2A continuous current per channel, ideal for medium-power robotic applications. Built-in current limit protection for safer motor operation. Compatible with 3.3V and 5V logic input, supporting various Arduino boards. DRV8871 IC ensures smooth, efficient, and reliable motor control. Selectable control modes: Signed Magnitude and Locked Anti-Phase via DIP switches. Stackable header pins for easy integration with additional shields. Quick-test switches provided for rapid motor testing on both channels. Includes dedicated connector for Cytron LSS05 Line Sensor, ideal for line-following robots. (Note: No polarity protection for motor supply input - connect with care.)

7Semi BME680 Temperature, Humidity, Pressure & Air Quality Sensor Breakout with Qwiic Interface The 7Semi BME680 Environmental Sensor Breakout is a compact yet powerful module designed for applications that require accurate measurement of temperature, humidity, pressure, and indoor air quality. Built around the trusted Bosch BME680 sensor, it provides dependable multi-parameter environmental data in real time, making it ideal for IoT projects, smart home automation systems, and portable environmental monitoring devices. Its efficient gas sensor intelligently detects VOC levels, helping you assess indoor air quality with ease. Engineered for universal compatibility, this breakout includes both a voltage regulator and level shifter, enabling seamless integration with 3.3V and 5V microcontroller platforms such as Arduino and Raspberry Pi. The Qwiic connector and I2C/SPI support ensure quick setup without messy wiring, while its compact size makes it perfect for wearables and space-constrained builds. With low-power operation, stable readings, and selectable I2C addresses, this module provides developers with a simple and reliable way to enhance environmental sensing in modern embedded projects. Features: Provides accurate measurement of temperature, humidity, pressure, and VOC-based air quality, making it an all-in-one environmental sensor solution. Supports I2C and SPI communication, ensuring smooth integration with Raspberry Pi, Arduino, ESP32, and other development boards. Includes selectable I2C addresses (0x76/0x77) to allow multiple sensors on a single bus without conflicts. Features a built-in voltage regulator and level shifting circuitry, allowing safe use with both 3.3V and 5V systems. Designed with low power consumption, suitable for long-term, battery-powered, or portable applications. Comes in a compact 19×19 mm breakout form factor, perfect for handheld devices, IoT wearables, and mini weather stations. Provides stable VOC readings after a short burn-in time, ensuring reliable indoor air quality measurements.

SmartElex RJ45 magjack Connector Breakout Board The SmartElex RJ45 MagJack Connector Breakout Board is a convenient module designed to make Ethernet connectivity accessible for custom electronics projects. It breaks out an RJ45 Ethernet jack with integrated magnetics, allowing users to interface network signals with development boards, prototypes, and embedded circuits without needing to design their own connector layout. This board is ideal for students, makers, engineers, educators, and startups who want to experiment with wired networking, communication protocols, or LAN-based control in robotics and IoT applications. This RJ45 MagJack breakout board is commonly used in IoT networks, automation systems, communication modules, and hardware prototypes that require Ethernet access for data transfer or device control. It can be used with platforms like Arduino, Raspberry Pi, ESP32, and other microcontroller boards that support Ethernet interfacing through additional hardware or modules. With reliable connectivity and a beginner-friendly breakout design, the SmartElex RJ45 MagJack Connector Breakout Board is a practical choice for testing, learning, and developing Ethernet-enabled electronic devices and embedded systems. Features: Breaks out an RJ45 MagJack Ethernet connector to easy-to-use pins Simplifies Ethernet interfacing for prototyping and custom circuits Integrated magnetics for stable network signal handling Compatible with Arduino, Raspberry Pi, ESP32 (with Ethernet support) Ideal for IoT, automation, LAN communication, and embedded systems Great for testing, learning, and building Ethernet-enabled devices

SmartElex HTU21D-F Temperature and Humidity Sensor with Breakout Board The SmartElex HTU21D-F Temperature and Humidity Sensor with Breakout Board is a compact and reliable temperature and humidity sensor designed for accurate environmental monitoring. It helps users measure ambient temperature and humidity digitally with stable output, making it suitable for students, makers, educators, and engineers working on sensing and monitoring applications. This digital temperature and humidity sensor is ideal for those who want dependable readings without complex circuitry, especially in learning, testing, and early product development environments. This I2C digital humidity sensor is widely used in IoT systems, weather monitoring projects, automation setups, and data logging applications where consistent environmental data is required. It integrates easily with popular development platforms such as Arduino, Raspberry Pi, and ESP32, allowing quick setup and smooth communication through the I2C interface. With its breakout board design and reliable performance, the SmartElex HTU21D-F sensor is well suited for prototyping, robotics projects, and educational labs looking for a practical alternative to traditional sensors like SHT15 breakout boards. Features: Digital temperature and humidity sensor with stable and accurate readings I2C interface for simple and reliable data communication Compact breakout board for quick prototyping and testing Easy to use with Arduino, Raspberry Pi, and ESP32 platforms Suitable for IoT, automation, and environmental monitoring projects Ideal replacement option for older sensors like SHT15 breakout boards

7Semi BMP581 High-Precision Barometric Pressure & Altitude Sensor Breakout The 7Semi BMP581 Barometric Pressure & Altitude Sensor Breakout is engineered for projects that demand highly accurate atmospheric pressure and altitude data. Built on Bosch’s advanced sensing technology, this compact module delivers exceptional precision with ±30 Pa absolute accuracy and ±6 Pa relative accuracy, translating to altitude precision as fine as ±0.5 meters. Its ability to operate across a wide 300–1250 hPa pressure range makes it ideal for applications like weather stations, environmental monitoring, and UAV altitude tracking. Designed for effortless integration, the BMP581 supports I2C, I3C, and SPI interfaces, making it compatible with a wide range of development boards and embedded systems. The Qwiic connector ensures solder-free wiring, while the low-power operation makes it suitable for portable and battery-powered devices. Whether you're building an IoT sensor node, a smart altimeter, or barometric logging system, this breakout brings reliable performance, high sensitivity, and fast data rates, perfect for altitude measurement and barometric pressure sensing projects. Features: Provides high-precision barometric readings with ±30 Pa absolute accuracy and ±6 Pa relative accuracy for reliable altitude measurement. Offers extremely fine resolution down to 1/64 Pa, ensuring smooth and accurate environmental data output. Includes Qwiic Connect support for solder-free I2C connectivity along with 0.1" header pins for SPI or wired I2C connections. Operates with ultra-low power consumption, only 1.5 µA in deep standby and 260 µA during active measurements. Covers a wide pressure sensing range from 30 to 125 kPa with high output data rates up to 622 Hz for real-time applications. Provides flexible configuration options, including adjustable oversampling, FIFO buffer, and low-pass filtering for optimized performance. Features 6 bytes of onboard non-volatile memory for storing user-specific calibration or configuration data.

7Semi DC-DC Buck Converter 5V 3A Out - MP2338 (BO-10182) The 7Semi DC-DC Buck Converter 5V 3A Out – MP2338 (BO-10182) is a compact power module designed to step down higher DC voltages to a stable 5V output with up to 3A current. It provides reliable and efficient power for electronics that require a steady 5V supply, such as microcontrollers, sensors, and development boards. Built around the MP2338 step-down converter, this module offers high efficiency and stable performance while minimizing heat and power loss. It supports a wide input voltage range and includes built-in protection features for safe operation. Whether you’re working on embedded systems, IoT devices, or custom electronics projects, this buck converter makes power management simple and dependable. Features: Boosts power efficiency with a high-performance MP2338 buck converter Provides a stable 5V output at up to 3A for reliable powering Wide input voltage range, compatible with various DC sources Compact breakout module for easy PCB or project integration Built-in protection features for safe and stable operation Ideal for microcontrollers, sensors, IoT boards, and embedded systems

7Semi BME688 Environmental Sensor Nano Breakout with 2.54mm Pitch Header The 7Semi BME688 Environmental Sensor Nano Breakout with 2.54mm Pitch Header is a versatile and high-precision environmental sensor designed for modern monitoring applications. Built around Bosch’s advanced BME688, it accurately tracks temperature, humidity, air pressure, and gas levels, helping you gain meaningful insights into environmental conditions. Its compact nano form factor and I2C interface make integration simple with Arduino, Raspberry Pi, and other development boards. Whether you’re building a smart home system, an industrial monitoring setup, or an environmental research project, this environmental monitoring sensor delivers dependable performance in a user-friendly design. Features: AI-Enhanced Gas Sensing: Identifies dangerous gasses with exceptional accuracy. Comprehensive Monitoring: A single sensor measures numerous essential environmental factors. Flexible Interface: I2C connectivity enables seamless interaction with microcontrollers. Compact design: The nano breakout board is ideal for projects with limited space. 3.3V Operating Voltage: Suitable for a wide range of development boards. Gas sensor sensitivity, selectivity, and data rate can all be adjusted to meet your individual application requirements.

Seeed Studio XIAO ESP32S3 Sense – Wi-Fi, BLE & AI Camera Board If you want a small but powerful development board, pick the Seeed Studio XIAO ESP32S3 Sense. It is ideal for IoT and embedded machine-learning projects. This seeed studio ESP32 board has a powerful Xtensa processor ESP32-S3R8 SoC that provides dependable 2.4GHz Wi-Fi and Bluetooth BLE 5.0. It has an OV3660 smart camera sensor board for crisp 1600*1200 quality photos and a built-in digital microphone for voice detection and audio recognition. You'll love the 8MB PSRAM and 8MB FLASH, plus an SD card slot for up to 32GB of extra storage. It supports battery charging, making it great for portable projects, and it’s versatile with its wide range of interfaces. The XIAO ESP32S3 Sense also offers pre-trained AI models and no-code deployment through SenseCraft AI. Despite its powerful features, it maintains the classic thumb-sized form factor of the XIAO family. This board is a fantastic choice for your next project! Features: Features a powerful ESP32S3 32-bit dual-core processor. It supports Arduino and MicroPython. Includes a detachable OV3660 camera for 1600*1200 resolution. Includes an integrated digital microphone. Measuring just 21 x 17.5mm. Has 8MB PSRAM, 8MB FLASH, and an SD card slot for up to 32GB of memory. Supports 2.4GHz Wi-Fi and BLE with a 100m+ range using a U.FL antenna. Provides pre-trained AI models from SenseCraft AI for no-code deployment. Camera & ML Demo: Sample Projects DIY Face Detection Camera : Use the XIAO ESP32S3 Sense built-in camera and on-board ML support to detect faces, capture snapshots, and send alerts over WiFi. Smart Door Entry Monitor : Combine the camera with a PIR sensor to capture entry events, log timestamps, and stream snapshots to a dashboard. Voice and Camera Surveillance : Use the digital microphone and camera together to detect sound and motion, then record short clips or trigger notifications. Object Classification Station : Run small image classification models on the S3 Sense to identify objects on a workbench or conveyor belt and log results to local storage or the cloud. Portable Field Camera Node : Deploy the board with battery power and SD storage to capture and store images in remote locations for later analysis. Comparison: C3 vs S3 Sense Feature XIAO ESP32-C3 XIAO ESP32S3 Sense Processor ESP32-C3 single core, up to 160 MHz ESP32-S3 dual core, up to 240 MHz Memory Lower flash and no PSRAM on most variants Includes PSRAM and larger flash, microSD support on some SKUs Camera No built-in camera Built-in OV camera module and digital microphone On-device ML Limited for tiny models Better suited for vision and audio ML tasks Ideal Use Cases Low power IoT nodes, BLE peripherals, simple sensors AI camera projects, voice and vision prototypes, edge ML demos Form Factor XIAO compact size XIAO compact size with camera and sensor additions Related Products & Modules XIAO Series Collection IoT Sensors Collection Tutorial : Build a DIY Face Detection Camera Use the XIAO ESP32S3 Sense, attach power and optional microSD card, flash a sample face detection sketch using Arduino or MicroPython, and configure WiFi to stream or upload detection events to your dashboard. For best results use lightweight models optimized for the S3 Sense and test in varied lighting conditions. Suggested steps: Prepare hardware: XIAO ESP32S3 Sense, power source, optional microSD, and a PIR sensor if needed. Install toolchain: Arduino IDE or MicroPython firmware and required libraries for camera and ML inference. Load sample code: run a face detection example, adjust model thresholds and frame size for performance. Configure output: save snapshots to microSD or push events to a dashboard via MQTT or HTTP. Test and tune: iterate on model size, resolution, and detection thresholds for reliable results. Application: Speech recognition Video monitoring Wearable devices Image processing Smart homes Low-power (LP) networking Rapid prototyping Health monitoring Education

7Semi DC Buck Converter Breakout 5V 2A Out (AP62301) (BO-10133) The 7Semi DC Buck Converter Breakout 5V 2A Out (AP62301) is a small power module that converts higher DC input voltages into a steady 5V output with up to 2A current. It allows you to power 5V-based electronics from a wide range of DC power sources such as batteries and adapters. This makes it perfect for projects that need a reliable 5V supply. Built with an efficient synchronous buck converter design, this module delivers stable power while keeping energy loss and heat to a minimum. Its compact size makes it easy to add to space-limited electronics projects like IoT devices, microcontroller boards, and portable systems. Whether you’re building sensors, development boards, or embedded systems, this buck converter gives you a simple and dependable way to get 5V power. Features: Provides a stable 5V output with up to 2A continuous current Accepts a wide range of DC input voltages for flexible power sources Efficient synchronous buck converter design for low power loss Low heat generation for cool and reliable operation Compact breakout board for easy integration and prototyping Ideal for powering 5V microcontrollers, sensors, and IoT devices Perfect for embedded systems, portable electronics, and hobby projects

Cytron ESP8266 WiFi Shield for Arduino with WROOM-02 Module The Cytron ESP8266 WiFi Shield is a beginner-friendly, plug-and-play solution that makes adding WiFi connectivity to Arduino projects incredibly easy. Powered by the reliable ESP8266 WROOM-02 module, this shield eliminates the wiring complications and level-shifting issues commonly faced when using standalone ESP modules. With preloaded Cytron_ESP_AT Firmware V2.2.0, onboard 3.3V regulation, selectable UART pins, and support for AT-command control, it is the perfect choice for IoT applications, wireless sensor systems, home automation, and connected electronics. Designed with the Arduino R3 layout, this WiFi shield works seamlessly with Arduino UNO, Maker UNO, CT-UNO, CT-ARM, and various compatible boards. It also offers direct programming access to the ESP8266, breakout I/O pins, and optional microSD card support for data logging. Whether you're uploading custom firmware or using AT commands for WiFi communication, the Cytron ESP8266 WiFi Shield delivers stable wireless performance, strong signal output, and unmatched ease of integration, making it ideal for both beginners and advanced IoT developers. Features: Compatible with Arduino R3 layout boards including Maker UNO, CT-UNO, CT-ARM, Arduino UNO R3, and Arduino Leonardo. Preassembled with ESP8266 WROOM-02 module and flashed with Cytron_ESP_AT V2.2.0 firmware. Onboard 3.3V regulator capable of supplying up to 500mA for stable WiFi operation. Selectable UART/Serial communication via mini jumpers (USB, hardware serial, software serial options). Supports 802.11 b/g/n, Wi-Fi Direct (P2P), Soft-AP mode, and full TCP/IP protocol stack. Integrated TR switch, balun, power amplifier, LNA, PLLs, regulators, and 32-bit CPU. +19.5 dBm output power for strong wireless range. Breakout pins available for programming or full I/O access of WROOM-02. Includes optional microSD slot for data logging and local storage. Each shield is fully assembled and tested before shipping.

7Semi MCP23017 I2C to 16 IO Expander Breakout Board The 7Semi MCP23017 I2C to 16 IO Expander Breakout Board is designed to expand the digital I/O capability of microcontrollers using the trusted MCP23017 I2C IO Expander IC. It provides exactly 16 configurable GPIO pins over a single I2C bus, reducing wiring complexity while maintaining stable performance. Each pin can be independently set as input or output, and the onboard interrupt feature allows the controller to respond instantly to pin state changes. This MCP23017 Breakout Board is compact, easy to integrate, and ideal for applications such as home automation, robotics, industrial control panels, and any project that requires multiple digital inputs and outputs without consuming extra microcontroller pins. Features: 16 I/O Pins: Converts two signal pins into sixteen completely customizable I/O pins. Multi-board Expansion: For larger applications, stack up to 8 boards to provide up to 128 I/O pins. Configure I2C addresses by setting the A0, A1, and A2 jumpers. Dual Connectivity: Includes PH2.0 terminal and solder pad choices for simple connection. Wide Compatibility: Compatible with both 3.3V and 5V systems, ensuring platform versatility. Interrupt Support: The INTA and INTB interrupt pins are used for real-time signal handling. Development Resources: Includes detailed instructions and sample projects for Raspberry Pi, Arduino, STM32, and micro. Easy Integration: The I2C interface, combined with a 4Pin 2.0 mm JST connector, provides for an easy and flexible connection to any MCU.
