SmartElex VL53L5CX ToF Image Sensor
Delivery & Pickup Options
Pick up today from our store.
Estimated delivery: 2-5 business days
SmartElex VL53L5CX ToF Image Sensor The SmartElex VL53L5CX ToF Image Sensor is a compact, high-performance ToF Image Sensor designed for precise short-range distance sensing and spatial awareness. Based on ST’s advanced VL53L5CX chipset, this 64 pixel Time-of-Flight (ToF) 4 meter ranging sensor combines a SPAD array, infrared filters, and diffractive optical elements (DOE) to deliver consistent and accurate ranging even under challenging ambient lighting and different cover glass materials. It supports multizone distance measurements up to 4000 mm across all 64 zones with a wide 63° field-of-view, operating at up to 15 Hz. ST’s patented histogram algorithms enable reliable detection of multiple objects within the FoV while minimizing crosstalk beyond 60 cm. This short range ToF sensor is ideal for applications like 3D room mapping, robotics obstacle detection, gesture recognition, IoT systems, laser-assisted autofocus, and AR/VR enhancements. Note: The VL53L5CX is unique in that it requires firmware to be loaded via the I2C bus at power-on. Because this firmware is ~90k bytes, we recommend a microcontroller with enough storage to hold both the VL53L5CX firmware and your program code. Features: Model: VL53L5CX. Multizone ranging output with 4x4 or 8x8 independent zones. Up to 400 cm range 60 Hz frame rate capabilities. Operating voltage: 3.3 volts. I2C Address: 0x52. Emitter: 940 nm invisible light vertical cavity surface emitting laser (VCSEL), with integrated analog driver. Using diffractive optical elements (DOE) on both transmitter and receiver, the field of view is 63 degrees diagonally square.
- 64 pixel Time-of-Flight (ToF) 4 meter ranging sensor for accurate multi-zone distance measurement
- Built on ST VL53L5CX short range ToF sensor with integrated SPAD array
- Uses diffractive optical elements (DOE) and infrared filters for reliable performance in varying light
- Measures distances up to 4000 mm across 64 zones simultaneously
- Wide 63° diagonal field-of-view with refresh rates up to 15 Hz
- Plug-and-play design with optional 0.1″ breadboard-compatible pins (no soldering required)
- Model No. VL53L5CX
- Voltage Rating (V) 3.3V
- I2C Address 0x52
- PCB Size (L × W) 25.4 × 25.4 mm
- Frame Rate 60 Hz
