Tactile 4 Pin Push Button Switch - Pack of 5 ( 12x12x7.3 mm ) 6x6x6mm Tactile 4 Pin Push Button Switch is widely used as a standard input buttons on electronic projects. These push button switch work best when you mount it on PCB but can also be used on a solderless breadboard for temporary connections in prototypes. The pins are normally open (disconnected) and when the button is pressed they are momentarily closed and complete the circuit. This tact switch also offers reliable dome contact technology and strong tactile feedback, with multiple operating forces to choose from. Applications: Can be used in Prototyping Can be used in DIY Projects for triggering input. Can be used with Arduino for IOT Applications Explore our broad range of Push Button Switch !

Tactile 4 Pin Push Button Switch 12X12X10mm (Pack of 5) The Tactile 4 Pin Push Button Switch 12x12x10mm (Pack of 5) is a reliable and compact input component designed for various electronic applications. This tactile switch provides a satisfying click response, ensuring precise control and user feedback. Its 4-pin design allows for easy PCB mounting or temporary breadboard connections, making it perfect for DIY projects and prototypes. With a durable dome contact mechanism and stable performance, this tactile switch 4 pin is commonly used in consumer electronics, telecommunications, testing instruments, and computer peripherals. Features: 12x12x10mm compact tactile switch design 4-pin configuration for stable connections Normally open (closes when pressed) Compatible with PCB and breadboard setups Strong tactile response for better user control Long-lasting dome contact mechanism Used in consumer electronics, medical devices, computers, and testing instruments

Tactile Push Button Switch 4 Pin 12X12X5mm (Pack of 5) The Tactile Push Button Switch 4 Pin 12x12x5mm is a compact and reliable tactile switch 4 pin component designed for versatile electronic applications. With its momentary action and crisp tactile feedback, it ensures accurate control input in devices like control panels, embedded systems, and DIY projects. The 12x12x5mm low-profile form factor allows for easy installation in tight spaces, whether for surface mount or through-hole configurations. Sold in a pack of 5, this tactile push button switch is ideal for OEMs, hobbyists, and engineers looking for dependable switching performance in their electronic designs. Features: Compact Size (5mm Height) Suitable for space-limited electronics. The four-pin design ensures sturdy attachment and contact. When the momentary action switch is released, it returns to its default state. Dual Mounting Support Works with both the THT and SMD procedures. Standard Electrical Rating: 12V DC, 50mA to 100mA. Applications: OEM control panels and remotes Electronics that are compact and embedded Consumer devices and interface buttons Audio/visual system controls Test equipment and microcontroller inputs

Tactile Push Button Switch Assorted Kit - 25 Pieces pack This Kit has 25 tactile buttons with five different colored caps are great for all sorts of projects. Feature momentary contact, 4 pins, rectangular push button, through-hole mounting, 12 x 12 x 7.1 mm size, etc. Used in the fields of electronic products, household appliances, and more. The tact push button switch is widely used in appliance, electric torch, flashlight, or electronic DIY projects. Additionally, the kit comes with a plastic box with a separate section for each color to keep it systematically.

Tactile Push Button Switch Assortment Kit – 180PC 10 Value 6x6mm 4 Pin The Tactile Push Button Switch Assortment Kit includes 180 high-precision micro switches in 10 different sizes, ranging from 4.3mm to 14mm. Each switch features a durable metal cover and a smooth plastic button for a comfortable and reliable pressing experience. Designed with a 12V operating voltage and 0.05A current rating, these switches provide stable, momentary contact performance suitable for a wide range of electronic projects. Perfect for DIY electronics enthusiasts, students, and repair professionals, this set is ideal for use in devices like remote controls, 3D printers, computer peripherals, home appliances, and more. The assortment comes neatly packed in a sturdy plastic storage box with compartments for each size, making it easy to organize, identify, and access the switches during projects. Features:

3pin Percussion Knocking Knock Sensor Module The Tap sensor module is a piezoelectric device, which creates an electrical signal when mechanically deformed by a tap or knock, is commonly used as the sensor. The sensor module most likely contains the piezoelectric element as well as extra circuitry to amplify and condition the piezoelectric element's output signal. The sensor's output can be a digital signal, such as a change in voltage level or a pulse, that can be read by a microcontroller or other device. These sensors have a wide range of applications, including security systems, human-machine interfaces, and toys, where the detection of a tap or knock is required. Knock sensor module and a digital 13 interface, built-in LED build a simple circuit to produce percussion flasher. Interface comes with digital LED, will knock sensor connected digital 3 interface, when percussion sensor senses measure to percussive signals, LED flashing light.

TB6560 Stepper Motor Driver The TB6560 Stepper Motor driver board is for axis control with Input signal high-speed optocoupler isolation, and a large heat sink to ensure good heat dissipation. The Stepper motor driver is Semi-flow mode adjustable, and semi-flow current adjustable, with a variety of semi-flow model and semi-flow current setting functions. It is very easy to use and requires no special instructions. The module features Semi-flow mode adjustable, and semi-flow current adjustable, not the general design on the market, with a variety of semi-flow models and semi-flow current setting functions. This stepper motor driver is featuring a TB6560AHQ new original chip. The TB6560AHQ has a low voltage shutdown, overheating stop, and overcurrent protection circuit to ensure optimal performance. The TB6560 stepper motor control circuit is the most commonly used current circuit, which can control a 2-phase motor (10 35VDC) with a maximum output of 3A. The TB6560 stepper motor control circuit is used for stepper motor control, CNC machine applications, or precision mechanical systems. If you want to use this TB6560 Stepper Motor Driver in your project, for that you will need Arduino , jumper wires , and batteries or a power supply. Features: Adjusts the current level to meet the needs of your specific application. Semi-automatic flow control. 6N137 high-speed optical coupling is used to ensure high speed without losing a step Setup instructions are printed on the board. Heat dissipation is improved by using a thick fine-toothed radiator. For 42,57,86 stepper motors up to 3A 2/4-phase / 4 wire / 6 wire, not suitable for motors higher than 3A. Synchronizing, half step, 1/8 step, 1/16 step, up to 16 segments. Half-decay occurs automatically. Applications: Micro-positioning and robotics Conveyors or OEM equipment CNC Machines

TB6600 Stepper Motor Driver TB6600 Stepper Motor Driver Controller 4A is an easy-to-use professional Arduino stepper motor driver, which can control a two-phase stepper motor . It is compatible with Arduino and other microcontrollers that can output a 5V digital pulse signal. Jumper wires are used to connect the stepper motor to the Arduino. TB6600 Arduino stepper motor driver has a wide range of power inputs and a 9~42VDC power supply . It is able to output a 4A peak current, which is enough for most of the stepper motors. The stepper driver supports speed and direction control. You can set its micro-step and output current with a 6 DIP switch. There are 7 kinds of micro-steps (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 kinds of current control (0.5A, 1A, 1.5A, 2A, 2.5A, 2.8A, 3.0A, 3.5A) in all. And all signal terminals adopt high-speed optocoupler isolation, enhancing its anti-high-frequency interference ability. As a professional device, it is able to drive 57, 42-type two-phase, four-phase, hybrid stepper motors. TB6600 Stepper Motor Driver Controller 4A 9~42V TTL 16 Micro-Step CNC 1 Axis Upgraded Version of the 42/57/86 Stepper Motor segment increased to 32 segments, suitable for high subdivision applications. Suitable for step motor:57, 42, 86 Type 4 phase 2 phase (4 line 6 line 8). Control signal connections: PUL +: positive pulse signal input. PUL-: pulse signal input negative. DIR +: the motor is, reverse the positive control. DIR-: the motor is, reverse the negative control. ENA +: positive control motor off. ENA-: motor off control of the negative. Motor winding connection: A+ : A + phase motor winding connection. A- : Connect the motor windings A- phase. B+ : B + phase motor winding connection. B- : B- phase motor winding connection. Supply voltage connection: VCC: positive power supply terminal “+” GND: negative power supply terminal “-“ check out : TB6560 Stepper Motor Driver Features: Bipolar constant current H bridge drive This has eight different types of output current available. This has six different subdivision modes are available. High-speed photoelectric isolation of the input signal Offline storage function. The semi-enclosed casing is capable of adapting to a more demanding environment. Provide a half-automatic current lock function to save energy. check out : DM542 Digital Stepper Motor Driver for CNC Drivers Controller 3D Printer Accessories Also check our dc motor speed control ( 9-60V 20A DC Motor Speed Controller), which is a reversible PWM switch with a metal shell and connective label, designed for DC brushed motors.

TB6600 Stepper Motor Driver Controller 8~50V 4.5A TB6600 stepper motor Driver Controller 4.5A 8~50V TTL 16 Micro-Step CNC Single-Axis Based on the TB6600HG chip, the new BL-TB6600-V1.2 driver model replaces the popular BL-TB6560-V2.0 driver. This driver controller is suitable for building not only amateur CNC systems but also professional ones based on high-power engines. Compared to the previous generation of the TB6560AHG, the output of the TB6600HG has increased to 200W (as we see a practical doubling in power value), the operating voltage is raised from 35V (TB6560AHG) to 50V, the operating current is increased to 4.5A (5A peak value). The main aspects of this driver include intelligent current control and the use of PWM modulation, which makes it possible to connect stepper motors of any supply voltage and current to the driver – at a fixed level; the chip itself will limit the maximum current. If you want to control the stepper motor with this motor driver, for that you will need a few essential components like Arduino jumper wires , batteries or power supply . Features: Supply Voltage: 8V – 50V DC (36V recommended) Output Current: 0.3A – 4.5A (peak value of 5A) Micro Step Settings: Supports 1, 2, 8, and 16 micro steps Maximum PWM Frequency: 200kHz Current Adjustments: Adjustable for maximum current settings of 1A, 2.2A, 3.3A, and 4.5A High-Speed Optocoupler Isolation: For signal terminals, enhancing anti-high-frequency interference ability Protection Features: Overheat, overcurrent, and short circuit protection Heat Dissipation: Large area heat sink for better heat dissipation Control Type: Supports speed and direction control Operating Temperature: -10 to +45 °C Applications: CNC Machines: Used in controlling stepper motors for precise movements in CNC milling, engraving, and cutting machines. 3D Printers: Essential for driving stepper motors in 3D printers, ensuring accurate layer deposition and movement. Robotics: Ideal for robotics projects requiring precise motor control, such as robotic arms and automated guided vehicles (AGVs). X-Y Tables: Used in X-Y tables for accurate positioning and movement in various industrial applications. Laser Cutters: Controls stepper motors in laser cutting machines for precise cutting and engraving. Pick-and-Place Devices: Employed in pick-and-place machines for accurate component placement in electronics manufacturing. Labeling Machines: Used in labeling machines for precise label application.

TB6612FNG Dual DC Motor Driver The Motor Driver TB6612FNG Module can control up to two DC motors at 1.2A constant current (3.2A peak). The motor can be controlled by two input signals (IN1 and IN2) in one of four function modes: CW, CCW, short-brake, and stop. The two motor outputs (A and B) can be controlled independently, and the speed of each motor is controlled by a PWM input signal with a frequency range of up to 100kHz. To remove the motor from standby mode, pull the STBY pin high. The logic supply voltage (VCC) can range from 2.7 to 5.5VDC, while the motor supply (VM) has a maximum voltage of 15VDC. The maximum output current per channel is 1.2A. (or up to 3.2A for a short, single pulse). All components are installed on the board as shown. On both supply lines, decoupling capacitors are installed. The TB6612FNG has all of its pins broken out to two 0.1?? pitch headers, with input pins on one side and output pins on the other. Features: Output current: Iout=1.2A(average) / 3.2A (peak) Standby control to save power CW/CCW/short break/stop motor control modes Built-in thermal shutdown circuit and a low voltage detecting circuit All pins of the TB6612FNG broken out to 0.1? spaced pins Filtering capacitors on both supply lines
