74HC00 - Quad 2-Input NAND Gate IC The 74HC Series 74HC00 IC is a 14-Pin Quad 2-Input NAND Gate IC. This device contains four independent gates each of which performs the logic NAND function. NAND gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. All gates have buffered outputs. All devices have high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and the ground. Pinout: Pinout Of 74HC00 IC Input Pins 1, 2, 4, 5, 9, 10, 12, 13 Output Pins 3, 6, 8, 11 Power Supply (VCC) 14 Ground (GND) 7 Applications: AV Receivers Portable Audio Docks Blu-ray Players and Home Theater MP3 Players or Recorders Personal Digital Assistants (PDAs) Power: Telecom or Server AC/DC Supply (Single Controller: Analog and Digital) Solid State Drives (SSDs): Client and Enterprise TVs: LCD, Digital, and High-Definition (HDTV) Tablets: Enterprise Video Analytics: Server Wireless Headsets, Keyboards, and Mice

74HC02 - Quad 2-Input NOR Gate IC The 74HC Series 74HC02 IC is a 14-Pin Quad 2-Input NOR Gate IC. NOR gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. All gates have buffered outputs, providing high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and the ground. Pinout: Pinout Of 74HC02 IC Also check 74LS12 NAND Gate IC (Pack of 5) . Which is used for logical decision making and circuits involving conditional operations.

74HC04 - Hex Inverter IC The 74HC Series 74HC04 is Hex Inverter NOT gate IC. It consists of six inverters that perform logical invert action. The output of an inverter is the complement of its input logic state i.e. when input is high its output is low and vice versa. The device contains six independent gates each of which performs the logic INVERT function. The operating voltage of this 74HC04 - Hex Inverter IC is 5V, the high-level input voltage is 2V, and the low-level input is 0.8V. Contains absolute maximum ratings over the operating free-air temperature range, recommended operating conditions, and electrical characteristics over recommended operating free-air temperature range. check out : Hex Schmitt Trigger Inverter IC - 74HC14 Pinout: Pinout Of 74HC04 IC

74HC08 - Quad 2-Input AND Gate IC The 74HC Series 74HC08 is Quad 2-Input AND Gate 14 Pin IC. The 74HC08 provides 4 independent 2-input AND gates with standard push-pull outputs. The device is designed for operation with a power supply range of 2.0V to 6.0V. It utilizes advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. The HC08 has buffered outputs, providing high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and the ground. check out : Dual 2-to-4 line Decoder/Demultiplexer IC - 74HC139 Pinout: Pinout Of 74HC08 IC

74HC11 - Triple 3-Input AND Gate IC The 74HC11 is a digital integrated circuit (IC) with three separate 3-input AND gates. It belongs to the 74HC family of integrated circuits, which are high-speed CMOS (Complementary Metal-Oxide-Semiconductor) devices with quick switching rates and low power consumption. The 74HC Series 74HC11 has three inputs and one output for each AND gate. Only if all of the inputs are high is the output (logic 1) high (logic 1). The output is low if any of the inputs is low (logic 0). (logic 0). As a result, the 74HC11 can be used to create logic functions that require the combination of many signals. The 74HC11 comes in a typical DIP (Dual In-line Package) form factor and is easily incorporated into circuits utilising through-hole technology. It can handle input and output voltages ranging from 0V to Vcc and operates across a wide voltage range of 2V to 6V. Pinout: Pinout Of 74HC11 IC

74HC138 - 3-to-8 line Decoder/Demultiplexer IC The 74HC Series 74HC138 decoder utilizes advanced silicon-gate CMOS technology and is well suited to memory address decoding or data routing applications. The circuit features high noise immunity and low power consumption usually associated with CMOS circuitry, yet has speeds comparable to low-power Schottky TTL logic. The 74HC138 has 3 binary select inputs (A, B, and C). If the device is enabled, these inputs determine which one of the eight normally HIGH outputs will go LOW. Two active LOW and one active HIGH enable (G1, G2A, and G2B) are provided to ease the cascading of decoders. The decoder’s outputs can drive 10 low-power Schottky TTL equivalent loads, and are functionally and pin equivalent to the 74LS138. All inputs are protected from damage due to static discharge by diodes to VCC and the ground. Pinout: Pinout Of 74HC138 IC Also check the 74139 Dual Decoder-Demux IC . It is a digital logic IC used to convert a two-line binary input signal into one of four output signals. The IC has two active-low enable inputs (E1 and E2) and two data inputs (D1 and D2). When both enable inputs are high, the outputs are inactive, and when one of the enabled inputs is low, the corresponding data input is passed through to the outputs.

74HC151 - 8-Input Multiplexer IC The 74HC Series 74HC151 is 8 - Input Multiplexer 16 Pin IC. Data Selector/Multiplexer contains full on-chip decoding to select one of eight data sources as a result of a unique three binary code at select inputs. Two complementary outputs provide both inverting and non-inverting buffer operations. A Strobe input is provided which, when at a high level, disables all data inputs and forces Y output to a low state and W output to a high state. Select input buffers incorporate internal overlap features to ensure that select input changes do not cause invalid output transients. Used for Boolean Function Generator. check out : CD4047 - Astable/Monostable Multivibrator IC Pinout: Pinout Of 74HC151 IC Application: Used for Boolean Function Generator

74HC165 - 8-Bit Parallel In/Serial Out Shift Register IC The 74HC Series 74HC165 high-speed PARALLEL-IN/SERIAL-OUT SHIFT REGISTER utilizes advanced silicon-gate CMOS technology. It has the low power consumption and high noise immunity of standard CMOS integrated circuits, along with the ability to drive 10 LS-TTL loads. This 8-bit serial shift register shifts data from QA to QH when clocked. Parallel inputs to each stage are enabled by a low level at the SHIFT/LOAD input. Also included is a gated CLOCK input and a complementary output from the eighth bit. Clocking is accomplished through a 2-input NOR gate permitting one input to be used as a CLOCK INHIBIT function. Holding either of the CLOCK inputs high inhibits clocking, and holding either CLOCK input low with the SHIFT/LOAD input high enables the other CLOCK input. Data transfer occurs on the positive-going edge of the clock. Parallel loading is inhibited as long as the SHIFT/LOAD input is HIGH. When taken LOW, data at the parallel inputs are loaded directly into the register independent of the state of the clock. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and the ground. check out : 4-bit Parallel-Access Shift Register IC - 74HC95 Pinout: Pinout Of 74HC165

74HC20 - Dual 4-input NAND Gate IC The 74HC Series 74HC20 is a 14-Pin Quad 4-Input NAND Gate IC. This device contains four independent gates each of which performs the logic NAND function. NAND gates utilize advanced silicon-gate CMOS technology to achieve operating speeds similar to LS-TTL gates with the low power consumption of standard CMOS integrated circuits. All gates have buffered outputs. All devices have high noise immunity and the ability to drive 10 LS-TTL loads. The 74HC logic family is functionally as well as pin-out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground. check out : Triple 3-Input NAND Gate IC - 74HC10 Pinout: Pinout Of 74HC20 IC

Product Information Logic Case Style: DIP Logic Type: Decoder / Demultiplexer MSL: - No. of Outputs: 8 No. of Pins: 16 Operating Temperature Max: 125 °C Operating Temperature Min: -40 °C Packaging: Each SVHC: No SVHC (17-Dec-2014) Supply Voltage Max: 6 V Supply Voltage Min: 2 V
