APM 2.8 Flight Controller (Without Compass) The APM 2.8 flight controller is an improved version of the APM 2.6 flight controller, suitable for use with DIY quadcopters, drones , helicopters, RC planes, and other UAVs. With its fail-safe programming option, drone enthusiasts can easily address issues caused by low battery or lost control signal. Additionally, this flight controller has an I2C interface that enables users to connect an external compass. The board also features pads at the back for the UART0, UART2, I2C, and OSD interfaces. The APM flight controller stands out for its open-source autopilot system, and the APM 2.8 flight controller is the top-selling model, recommended by UAV and Drone experts. It can turn any fixed or rotary-wing UAV into a fully autonomous system, and advanced users will appreciate the numerous customization options and expanded mission capabilities available. Check out the best collection of Drone Controllers . APM 2.8 Flight Controller Pinout: Features By using Mission Planner maps you can click and add waypoint entries. You can select your mission commands with a simple drop-down menu. Mission log files can be downloaded and analyzed. You can configure the settings of the APM controller to your airframe. You can create a hardware-in-the-loop UAV simulator by interfacing your PC flight simulator. You also have the option of viewing the output from APM’s serial terminal.

APM 2.8 Flight Controller with In-Built Compass We are thrilled to present to you the APM 2.8 Flight Controller with an integrated compass. For anybody looking to better their robotics or drone projects, this is a wonderful choice. This controller, an enhanced version of the APM 2.5 and 2.6, is suited for multi-rotor configurations and first-person viewpoint remote control aircraft. It works by using data from sensors to calculate the right speed for each motor, sending those commands to the Electronic Speed Controllers (ESCs) for smooth flight. You’ll also love the flexibility—it lets you use the built-in compass or connect an external one based on your needs. The APM 2.8 autopilot system, which is available as open-source software, has demonstrated its dependability by winning the Outback Challenge UAV competition. It can effortlessly manage preprogrammed GPS missions, regardless of you're using it to control autonomous vehicles like automobiles and boats or to fly drones. If you’re ready to take your projects to the next level, the APM 2.8 Flight Controller is a great choice. Let’s explore how it can work for you! Explore the exclusive collection of Drone Controllers . Key Features: Straight Needle design for easy connection. Arduino compatible for simple integration. 4 MB Dataflash chip for automatic data logging. Optional uBlox LEA-6H GPS module with compass. Invensense’s 6 DoF Accelerometer/Gyro MPU-6000 for accurate motion sensing. MS5611-01BA03 barometric pressure sensor for altitude measurement. Atmel’s ATMEGA2560 and ATMEGA32U-2 for reliable processing and USB functions. Wiring Diagram to use the built-in compass: To use the built-in compass, connect the jumper as indicated below. The APM board will use the external compass while the compass jumper is removed. Features of Powerful ground control software: Plan missions easily with point-and-click waypoint entry using Google Maps. Use simple drop-down menus to select mission commands. Download and analyze mission logs for performance insights. Customize APM settings for your specific airframe. Connect to a PC flight simulator for a realistic UAV experience. Monitor real-time output from APM’s serial terminal for quick troubleshooting.

Apm2.6 MWC GPS Compass Antenna Folding Fixed Mount Bracket Holder The Apm2.6 MWC GPS Compass Antenna Folding Fixed Mount Bracket Holder offers a professional and practical solution for mounting a folding GPS antenna. Crafted with durability in mind, this holder utilizes aluminium turning and CNC manufacturing techniques. It is compatible with a wide range of DJI quadcopters and multi-copters. Its simple installation and user-friendly design make it an excellent choice for those in need of a reliable GPS folding antenna holder. To optimize performance, it is advisable to use an extended mount that positions your GPS/Compass away from potential sources of interference and elevates it above your multirotor. This drone accessory features a height of 16cm, which is more than sufficient for most installations. Furthermore, the mount can be conveniently folded without requiring any tools, allowing for easy transportation and storage. Features: Made of aluminum and carbon & glass fiber Suitable for most DJI WKM Quadcopter Multicopter Adjustable arms to fit various GPS and compass module sizes Provides a secure and customizable fit for different modules Folding design for easy transportation and storage Arms can be folded down to make it more compact Convenient for fitting into a bag or case.

Arcade 2Pin Joystick switchable to 4/8 Ways This joystick can support the 8 way and 4-way models. The default is round 8 ways. If you need to use the 4 way, you just need flip No.5 small accessories. The NO interface is a Signal/Function Pin to a 4.8mm Connector. The COM interface is Ground Loop. Each joystick includes 4 high-quality micro switches. The service life is 1.000.000 times Be sure to assemble the joystick in the numerical order in the picture. Because it missed any of the steps. It will lose its job.

16 channel PWM Servo Motor Shield for Arduino The 16-Channel 12-bit PWM/Servo Driver Shield is designed for development boards compatible with Arduino which will drive up to 16 servos over I2C with only 2 pins. You can use jumper wires to connect. The onboard PWM controller will drive all 16 channels simultaneously with no additional board compatible with Arduino processing overhead. What's more, you can stack up to 62 of them to control even more servo motors - all with the same 2 pins. This shield is perfect if you want to build a robot, perhaps a hexapod or a project that requires several components that require movement. It is also ideal in controlling many LEDs with precise PWM signal and perform microprocessors has a limited number of PWM pins. For these applications, the shield of servo-motors with a PWM driver is the product you are looking for. Using this shield, 16-pin PWM can be controlled with just 2 pins I2C interface. Applications: RGB or RGBA LED drivers LED status information LED displays LCD backlights Keypad backlights for cellular phones or handheld devices

16X2 LCD Keypad Shield for Arduino The LCD keypad shield is suited for Arduino UNO board and Leonardo Board compatible with Arduino. The blue LCD Keypad Shield is sometimes called a navigation shield because it comes with 6 momentary push buttons for menu navigation. Besides the push button, it also includes a 2×16 LCD. This is a very popular LCD Keypad shield compatible with Arduino and other variants. It includes a 2×16 LCD display and 6 momentary push buttons. Pins 4, 5, 6, 7, 8, 9, and 10 are used to interface with the LCD. The onboard LED indicates power on. The 16 x 2 LCD shield is a great solution for an embedded systems engineer who wants to use an LCD module while plugged onto the Arduino. The 16 x 2 LCD module has a great design and is under friendly. It easily lets you keep connecting sensors to the rest of the pins, and use it for monitoring or menu selection with the push buttons even for gaming. Why is the 16 x 2 LCD Keypad shield necessary? As an embedded systems engineer, if you are planning to build a project which is not attached to a computer and you need to check what is going on when you place it on position, this addition will prove very valuable to make sure the program is running well. Pin Description Pin Function Analog 0 Buttons (select, up, right, down, and left) Digital 4 DB4 Digital 5 DB5 Digital 6 DB6 Digital 7 DB7 Digital 8 RS (Data or Signal Display Selection) Digital 9 Enable

2.4inch TFT Display for Arduino UNO board compatible with Arduino The TFT LCD display shield is designed with a built in microSD card connection. This TFT display is big (2.4? diagonal) bright (4 white-LED backlight) and colorful (18-bit 262,000 different shades) 240×320 pixels with individual pixel control. It has way more resolution than a black and white 128×64 display. This 2.4 inch TFT display is best suited for UNO boards compatible with Arduino . The 2.4 inch TFT LCD Touch Display Shield for Arduino Uno is fully assembled, tested and ready to go. Add the touch display without wiring, no soldering! Simply plug it in and load up a library – you ‘ll have it running in under 10 minutes! Works best with any classic Arduino ATMEGA328 Board. So spice up your Arduino UNO project with a beautiful large touchscreen display shield with a built-in microSD card connection.

3.2in TFT LCD Display Shield for Arduino The 3.2 TFT LCD display shield compatible with arduino is a powerful interface and is equipped with an SD card reader. It's powerful features allow multifunctional abilities for your projects.  The TFT LCD display is also user friendly as it helps the users with wiring. You can easily just plug the LCD display onto the Mega Board compatible with Arduino. Precautions while using the 3.2in TFT LCD Display Shield The control and driving circuit of TFT modules is low voltage and FRIDA micro-power CMOS circuit, can be easily damaged by static, static damage is an irreparable damage, and sometimes human have hundreds of volts of high voltage static electricity, therefore, in handling, assembling and use should be extremely careful to prevent static electricity: Using soldering iron or power FRIDA tools must be well grounded and operation, make them without leakage. Do not use hand to touch the leads, circuit boards and metal boxes. Do not use a vacuum cleaner for cleaning, because it generates strong static electricity; When the air is dry, can also generate static electricity, therefore, workshop humidity shall be above RH60%. If it is necessary to direct contact it , should enable the human body in the same potential with the modules ,or make human body be well grounded. Remove or back in the bags or move locations, also need to be careful to prevent static electricity. Don't replace or discard the original packing. Electrostatic damage or man-made damage is not within the scope of the warranty. Features: 3.2-inch TFT LCD : Provides a clear and vibrant display. 320x240 Resolution : High resolution for detailed visuals. SD Card Slot : Enables storage and display of images or data. Compatible with Arduino Boards : Works with various Arduino boards like Arduino Mega and Due. Easy Integration : Designed to stack on top of Arduino boards easily. Wide Viewing Angle : Ensures good visibility from different angles. Backlight Control : Adjustable backlight for better visibility in different lighting conditions. Applications: Personal digital assistants Portable instruments Point-of-sale terminals Pagers Cellular phones Weather monitoring system Package included: 1 x 3.2 inch TFT LCD display module

CNC Shield for Arduino The CNC shield for Arduino has total four slots, can drive 4 A4988 stepper motors. Each road stepper motors only need two IO ports. In other words, six IO ports can be well managed three stepper motors. The CNC Shield V3.0 allows you to build a engraving machine, 3D printer, mini CNC and other similar devices using your Arduino. It is designed as a shield and can plug on top of an Arduino requiring no external connections and wiring. There are 4 slots on the board for plugging in stepper motor drive module which can drive 1 stepper motor each. Controlling each step stepper motor requires only two IO pins on the Arduino. Just insert this Arduino CNC Shield V3.0 onto an Arduino UNO , and install the GRBL firmware, you can then quickly build a DIY CNC engraving machine. This arduino shield is very convenient to use and is suitable for development boards compatible with Arduino. This CNC shield compatible with Arduino is the latest version of the CN shield model (V 3.0). The CNC Shield is GRBL 0.9 compatible and with the help of jumper wires , it is accessible to stepper drivers. Features: Compact design. Stepper Motors can be connected with 4 pin molex connectors or soldered in place. GRBL 0.9 compatible. (Open source firmware that runs on an Arduino UNO that turns G-code commands into stepper signals) 4-Axis support (X, Y, Z , A-Can duplicate X,Y,Z or do a full 4th axis with custom firmware using pins D12 and D13)

Data Logger Shield for Arduino This data logger is best suited for UNO boards, Leonardo Boards or Mega boards compatible with Arduino . It helps these development boards to log sensor data to an SD card with the minimum of set-up. The shield contains appropriate level shifting circuitry to protect the 3.3V interface of your SD card. This data logger shield works well with UNO board , Diecimila, Leonardo , Mega Board and other microcontrollers compatible with Arduino . This Arduino shield is a dedicated and well designed to suite the functionalities of arduino. It is easy to assemble and customize, also equipped with extensive documentation and libraries. Features: Works with Arduino UNO, Duemilanove, Diecimila, Leonardo or ADK/Mega R3 or higher. ADK/Mega R2 or lower are not supported. A dedicated and well-designed data logging shield for Arduino. It is easy to assemble and customize, also equipped with extensive documentation and libraries. SD card interface works with FAT16 or FAT32 formatted cards. 3.3v level shifter circuitry prevents possible damage to your SD card. Real time clock (RTC) keeps the time going even when the Arduino is unplugged. Included libraries and example code for both SD and RTC mean you can get going quickly.
