V3 Version 863MHz-928MHz SX1262 ESP32 WIFI bluetooth Lora with 0.96 OLED Display

V3 Version 863MHz-928MHz SX1262 ESP32 WIFI bluetooth Lora with 0.96 OLED Display

(0)
V3 Version 863MHz-928MHz SX1262 ESP32 WIFI Bluetooth Lora with 0.96 OLED Display The ESP32 LoRa SX1262 0.96 Inch OLED Display Bluetooth WiFi Module for Arduino is a new development of the cost-effective networking program. The ESP 32 WiFi LoRa is a classic IoT dev-board designed & produced by Heltec Automation. Since its launch in 2017, it has been loved by developers and makers. The newly launched V3 version has the same pin sequence as the V2 version and retains Wi-Fi, BLE, LoRa, OLED display, and other functions. This loRa module has Onboard 32MByte Flash, Wi-Fi antenna, 0.96-inch blue OLED display, …
Condition: NEW
As low as ₹2113,10   ₹3498,60 Incl. GST (No Hidden Charges)
Backorder Available
OUT OF STOCK SKU#: IOT-2597
Backorder Available
You can place this order now with any quantity. We will prioritize fulfillment as soon as stock arrives.
Expected restock within 5-7 business days. We'll ship immediately once available.
For urgent inquiries, please contact us .
Delivery & Pickup Options
Backorder Available

Expected to be in stock within 5-7 business days. We'll ship immediately once available.

For bulk orders or wholesale inquiries, please contact us at Email: support@iotcart.in or call/message us at Phone: 8050206487.

V3 Version 863MHz-928MHz SX1262 ESP32 WIFI Bluetooth Lora with 0.96 OLED Display The ESP32 LoRa SX1262 0.96 Inch OLED Display Bluetooth WiFi Module for Arduino is a new development of the cost-effective networking program. The ESP 32 WiFi LoRa is a classic IoT dev-board designed & produced by Heltec Automation. Since its launch in 2017, it has been loved by developers and makers. The newly launched V3 version has the same pin sequence as the V2 version and retains Wi-Fi, BLE, LoRa, OLED display, and other functions. This loRa module has Onboard 32MByte Flash, Wi-Fi antenna, 0.96-inch blue OLED display, lithium battery charging circuit and interface, CP2102 USB to serial chip, the perfect support for Arduino development environment, can be very simple and fast for program verification and product development. It is the best option for smart cities, farms, homes, industrial control, house security, wireless meter reading, and IoT developers. check out : MKS TFT-WIFI V1.0 ESP8266 WIFI Module Pinout: Pinout Of V3 ESP32 WIFI Bluetooth Lora With 0.96 OLED Display

  • This is V3 Version 863MHz-928MHz SX1262 ESP32 WIFI bluetooth Lora with 0.96 OLED Display
  • Microprocessor: ESP32-S3FN8 (Xtensa® 32-bit LX7 dual-core processor, five-stage pipeline rack Structure, frequency up to 240 MHz).
  • SX1262 LoRa node chip.
  • Type-C USB interface with a complete voltage regulator, ESD protection, short circuit protection, RF shielding, and other protection measures.
  • Onboard SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery power detection, USB / battery power automatic switching).
  • Integrated WiFi, LoRa, Bluetooth three network connections, onboard Wi-Fi, Bluetooth dedicated 2.4GHz metal spring antenna, reserved IPEX (U.FL) interface for LoRa use.
  • Onboard 0.96-inch 128*64 dot matrix OLED display can be used to display debugging information, battery power, and other information.
  • Integrated CP2102 USB to serial port chip, convenient for program downloading, and debugging information printing.
Master Chip ESP32-53FN8 (Xtensa 32-bit lx7 dual core processor)
LoRa Chipset SX1262
USB to Serial Chip CP2102
Frequency 470 510 MHz, 863~928 MHz
Max. TX Power 21 + 1 dBm
Max. Receiving sensitivity -139 dBm
Battery 3.7V lithium battery power supply and charging
Operating temperature -20~70 °C
Dimensions 50.2x25.5x10.2 mm
Weight 5g
